Tecnomatic Panel Enclosure, 40 X 32 X 12 with Dead Front and Back Plate, Powder Coated, 28220-PD

Control Panel Enclosures with polyurethane gasket. Completely welded, solid front door, internal plate .

• Boxes & Enclosures Powder coated in textured RAL 7032 .
• Mounting plates and mounting brackets NOT INCLUDED.
• NEMA TYPE 4. UL/CUL approved. IP 55.
• Main body thickness 16ga.
• Internal mounting plate thickness 14ga.

Control Panel Enclosure with polyurethane gasket. Completely welded, solid front door, internal plate .

MODEL: 28220-PD, PRM PART # CONTJB28220PD

Technical Specs:

• Height (mm): 1006 / 40 IN
• Width (mm): 806 / 32 IN
• Depth (mm): 300 / 12 IN
• Doors: 1
• Locks: 2
• Weight (Kg): 49.7 / 110 LBS.

Click to Open Technomatic Industrial Enclosures Catalog PDF



Shipping

Larger boxes must ship via motor freight. To include the freight charges in your invoice, please contact us with your "Ship To" address for a freight quote. Shipping is not included in the price of the item.

For an accurate quote, please provide:

• Shipping Address with Zip
• Commercial or Residential Address
• Loading/Unloading dock and/or forklift available onsite.
