Productivity1000 Discrete Combo Module, Input: 8-point, 24 VAC/VDC, sinking/sourcing, Output: 8-point, 6-24 VDC/6-120 VAC
1 / 5
Productivity1000 Discrete Combo Module, Input: 8-point, 24 VAC/VDC, sinking/sourcing, Output: 8-point, 6-24 VDC/6-120 VAC
Productivity1000 discrete combo module, Input: 8-point, 24 VAC/VDC, sinking/sourcing, Output: 8-point, 6-24 VDC/6-120 VAC, relay, (8) Form A (SPST) relays, 1A/point. Requires P2-RTB or P2-RTB-1 removable terminal block or ZIPLink pre-wired cables.
| Item | Combo module |
| I/O Module Type | Discrete |
| Number of Input Points | 8 |
| Nominal Input Voltage | 24 VAC/VDC |
| Discrete Input Type | Sinking/sourcing |
| Number of Non-Isolated Discrete Input Commons | 1 |
| Number of Points per Discrete Input Common | 8 |
| Number of Output Points | 8 |
| Nominal Output Voltage | 6-24 VDC/6-120 VAC |
| Discrete Output Type | Relay |
| Relay Configuration | (8) Form A (SPST) relays |
| Load Current | 1A/point |
| Number of Non-Isolated Discrete Output Commons | 1 |
| Number of Points per Discrete Output Common | 8 |
| Fuse Type | External fusing 8A max (user supplied) |
| Requires | P2-RTB or P2-RTB-1 removable terminal block or ZIPLink pre-wired cables |
| Programming Software | Productivity Suite programming software v3.0 or later |
$43.50
Original: $144.99
-70%Productivity1000 Discrete Combo Module, Input: 8-point, 24 VAC/VDC, sinking/sourcing, Output: 8-point, 6-24 VDC/6-120 VAC—
$144.99
$43.50Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Productivity1000 discrete combo module, Input: 8-point, 24 VAC/VDC, sinking/sourcing, Output: 8-point, 6-24 VDC/6-120 VAC, relay, (8) Form A (SPST) relays, 1A/point. Requires P2-RTB or P2-RTB-1 removable terminal block or ZIPLink pre-wired cables.
| Item | Combo module |
| I/O Module Type | Discrete |
| Number of Input Points | 8 |
| Nominal Input Voltage | 24 VAC/VDC |
| Discrete Input Type | Sinking/sourcing |
| Number of Non-Isolated Discrete Input Commons | 1 |
| Number of Points per Discrete Input Common | 8 |
| Number of Output Points | 8 |
| Nominal Output Voltage | 6-24 VDC/6-120 VAC |
| Discrete Output Type | Relay |
| Relay Configuration | (8) Form A (SPST) relays |
| Load Current | 1A/point |
| Number of Non-Isolated Discrete Output Commons | 1 |
| Number of Points per Discrete Output Common | 8 |
| Fuse Type | External fusing 8A max (user supplied) |
| Requires | P2-RTB or P2-RTB-1 removable terminal block or ZIPLink pre-wired cables |
| Programming Software | Productivity Suite programming software v3.0 or later |
